HELUKABEL JZ-750控制电缆
| 刘洋 QQ：2850590582 手机：17744536447 电话：010-64714988-213 传真：010-64714988668 邮件：-@handelsen.cn |
 |
750 V，灵活，数字编码，仪表标记
技术数据特殊PVC控制电缆
，符合DIN VDE 0285-525-2-51 /
DIN EN 50525-2-51
-15°C至+ 80°C
固定安装时的温度范围 -40°C至+ 80°C固定安装
标称电压
U 0 / U 450/750 V
测试电压
4000 V
击穿电压
最小值 8000伏
最小弯曲半径
弯曲7,5
倍外径Ø固定安装4倍外径Ø
电缆结构
裸铜导体，细线符合 以 DIN VDE 0295 cl.5 / IEC 60228 cl.5符合DIN VDE 0207-363-3 / DIN EN 50363-3的TI2型特殊PVC 化合物的芯部绝缘根据DIN VDE 0293黑色芯线的芯线标识，并带有连续的白色编GN-YE导体，外层3芯及以上芯层绞合，铺设长度最佳根据DIN VDE 0207-363-4-1 / DIN EN 50363-4-1的TM2 特殊PVC 化合物类型的外套护套颜色：灰色(RAL 7001)带仪表标记物产广泛耐油，耐油/耐化学药品，请参阅“技术信息”制造过程中使用的材料不含镉，不含硅并且不含有害于漆润湿性的物质测验PVC自熄和阻燃认证 符合DIN VDE 0482-332-1-2 /DIN EN 60332-1-2 / IEC 60332-1-2
应用
这些电缆可灵活地用于中等机械应力，在干燥，潮湿和潮湿的房间中自由运动而无拉伸应力或强制运动，但不适用于需要国际认可的PVC电缆的露天场所。例如 作为控制或测量电缆，用于工业机械，输送机系统或工厂中的设备，等等。数字编码以易于识别的方式加到铁心上，并在铁心编号下划线以免造成混淆。
CE =产品符合低压指令2014/35 / EU。
|
零件号 |
核心数x |
外Ø 大约 毫米 |
警察。 公斤/公里 |
重量 大约 公斤/公里 |
特设工作组编号 |
|---|---|---|---|---|---|
|
2 x 0.5 |
5,7 |
9,6 |
48,0 |
20 |
|
|
3克0.5 |
6,0 |
14,5 |
65,0 |
20 |
|
|
4克0.5 |
6,8 |
20,0 |
81,0 |
20 |
|
|
5克0.5 |
7,4 |
24,0 |
98,0 |
20 |
|
|
7克0.5 |
8,3 |
34,0 |
123,0 |
20 |
|
|
8克0.5 |
9,1 |
38,0 |
155,0 |
20 |
|
|
10克0.5 |
10,0 |
48,0 |
180,0 |
20 |
|
|
12克0.5 |
10,8 |
58,0 |
208,0 |
20 |
|
|
14克0.5 |
11,7 |
67,0 |
248,0 |
20 |
|
|
16克0.5 |
12,5 |
76,0 |
260,0 |
20 |
|
|
18克0.5 |
13,2 |
87,0 |
285,0 |
20 |
|
|
21克0.5 |
13,8 |
96,0 |
375,0 |
20 |
|
|
25克0.5 |
15,5 |
118,0 |
400,0 |
20 |
|
|
30克0.5 |
16,6 |
144,0 |
475,0 |
20 |
|
|
40克0.5 |
18,7 |
192,0 |
590,0 |
20 |
|
|
50克0.5 |
21,5 |
240,0 |
710,0 |
20 |
|
|
61克0.5 |
23,0 |
293,0 |
880,0 |
20 |
|
|
2 x 0,75 |
6,2 |
15,0 |
60,0 |
19 |
|
|
3克0.75 |
6,5 |
22,0 |
78,0 |
19 |
|
|
4克0.75 |
7,3 |
29,0 |
104,0 |
19 |
|
|
5克0.75 |
8,0 |
36,0 |
116,0 |
19 |
|
|
7克0.75 |
8,9 |
51,0 |
148,0 |
19 |
|
|
8克0.75 |
9,6 |
58,0 |
160,0 |
19 |
|
|
10克0.75 |
10,7 |
72,0 |
195,0 |
19 |
|
|
12克0.75 |
11,6 |
87,0 |
248,0 |
19 |
|
|
15克0.75 |
13,2 |
108,0 |
295,0 |
19 |
|
|
18克0.75 |
14,1 |
130,0 |
346,0 |
19 |
|
|
21克0.75 |
14,8 |
151,0 |
395,0 |
19 |
|
|
25克0.75 |
16,6 |
180,0 |
505,0 |
19 |
|
|
34克0.75 |
19,3 |
245,0 |
684,0 |
19 |
|
|
41克0.75 |
20,9 |
296,0 |
780,0 |
19 |
|
|
50克0.75 |
22,9 |
360,0 |
940,0 |
19 |
|
|
61克0.75 |
24,5 |
440,0 |
1125,0 |
19 |
|
|
2 x 1 |
6,6 |
20,0 |
80,0 |
18 |
|
|
3 G 1 |
7,0 |
29,0 |
92,0 |
18 |
|
|
3 x 1 |
7,0 |
29,0 |
92,0 |
18 |
|
|
4 G 1 |
7,8 |
39,0 |
122,0 |
18 |
|
|
4 x 1 |
7,8 |
39,0 |
122,0 |
18 |
|
|
5克1 |
8,6 |
48,0 |
137,0 |
18 |
|
|
7 G 1 |
9,5 |
68,0 |
186,0 |
18 |
|
|
7 x 1 |
9,5 |
68,0 |
186,0 |
18 |
|
|
8 G 1 |
10,3 |
77,0 |
240,0 |
18 |
|
|
12克1 |
12,7 |
116,0 |
293,0 |
18 |
|
|
14克1 |
13,4 |
134,0 |
340,0 |
18 |
|
|
16 G 1 |
14,4 |
154,0 |
400,0 |
18 |
|
|
18克1 |
15,1 |
173,0 |
437,0 |
18 |
|
|
21 G 1 |
16,1 |
205,0 |
505,0 |
18 |
|
|
25克1 |
18,0 |
240,0 |
606,0 |
18 |
|
|
34 G 1 |
20,9 |
326,0 |
770,0 |
18 |
|
|
41 G 1 |
22,6 |
394,0 |
880,0 |
18 |
|
|
50克1 |
24,8 |
480,0 |
1400,0 |
18 |
|
|
61 G 1 |
26,5 |
586,0 |
1450,0 |
18 |
|
|
2 x 1,5 |
7,2 |
29,0 |
90,0 |
16 |
|
|
3克1,5 |
7,8 |
43,0 |
120,0 |
16 |
|
|
3 x 1,5 |
7,8 |
43,0 |
120,0 |
16 |
|
|
4克1.5 |
8,5 |
58,0 |
150,0 |
16 |
|
|
4 x 1,5 |
8,5 |
58,0 |
155,0 |
16 |
|
|
5克1,5 |
9,6 |
72,0 |
177,0 |
16 |
|
|
7克1,5 |
10,4 |
101,0 |
220,0 |
16 |
|
|
8克1,5 |
11,4 |
115,0 |
248,0 |
16 |
|
|
9克1,5 |
12,5 |
130,0 |
278,0 |
16 |
|
|
12克1.5 |
14,1 |
173,0 |
364,0 |
16 |
|
|
14克1,5 |
14,9 |
202,0 |
390,0 |
16 |
|
|
16克1,5 |
16,0 |
230,0 |
490,0 |
16 |
|
|
18克1.5 |
17,0 |
259,0 |
550,0 |
16 |
|
|
21克1.5 |
18,0 |
302,0 |
670,0 |
16 |
|
|
25克1.5 |
20,2 |
360,0 |
745,0 |
16 |
|
|
32克1.5 |
22,6 |
461,0 |
810,0 |
16 |
|
|
34克1,5 |
23,4 |
490,0 |
1010,0 |
16 |
|
|
42克1.5 |
25,5 |
605,0 |
1115,0 |
16 |
|
|
50克1,5 |
27,9 |
720,0 |
1430,0 |
16 |
|
|
61克1.5 |
30,0 |
878,0 |
1750,0 |
16 |
|
|
2 x 2,5 |
8,6 |
48,0 |
110,0 |
14 |
|
|
3克2,5 |
9,3 |
72,0 |
190,0 |
14 |
|
|
4克2,5 |
10,2 |
96,0 |
240,0 |
14 |
|
|
5克2,5 |
11,4 |
120,0 |
270,0 |
14 |
|
|
7克2,5 |
12,6 |
168,0 |
350,0 |
14 |
|
|
12克2,5 |
16,9 |
288,0 |
600,0 |
14 |
|
|
14克2,5 |
18,2 |
336,0 |
870,0 |
14 |
|
|
18 G 2,5 |
20,4 |
432,0 |
1050,0 |
14 |
|
|
25克2,5 |
24,4 |
600,0 |
1170,0 |
14 |
