Parvalux永磁刷直流电机PM60 DC Motor Family
| 金仕宇 QQ：2850590587 手机：15711496495 电话：010-64714988-212 传真：010-64714988-668 邮件：tk6@handelsen.cn |
 |
Parvalux永磁刷直流电机PM60 DC Motor Family
有刷电机系列Parvalux PM60是一种永磁刷直流电机，专为需要频繁换向的应用而设计。它是弹簧负载的安静运行有一个高启动扭矩3倍满载。它有一个可调的电刷摇杆，以确保最大的电刷寿命和提供良好的换向。其压力压铸机壳确保同心气隙和正确的轴承对准。我们提供多个级别的定制服务，从标准“选项”如轴变化、输出法兰选项、各种电缆长度、制动器、编码器、油漆饰面和接线盒，到完整的定制解决方案，包括整合驱动链其他组件的能力。我们的应用和工程团队也有广泛的应用特定知识，所以请立即致电或发送电子邮件给我们，为您的产品需求提供完美的解决方案。 电动机类型 PMDC公司 变速箱 排队 扭矩 0.7-1.1牛米 速度 1500-4000转/分 权力 105-575瓦 制动器 对 电容器尺寸 不 轴径 不 轴特征 平孔键槽 轴材料 钢/不锈钢 轴输出 可根据要求提供单端或双端 接线盒 对 接线盒位置 在上面 电压 12直流-220直流 重量 2.9千克 比率 不 极 不 阶段 不 油漆 不 噪声级 不 安装 B14/M56/M63，IEC IP等级 防护等级21 绝缘等级 F 外壳材料 压铸锌合金 齿轮材料 不 框架类型 PARVALUX框架 编码器 对 圈地 全封闭式 效率 不 效率等级 不 占空比 续 当前 *联系销售支持了解负载电流 连接 飞线300mm 所获证书 不
parvalux成立于1947年，作为英国最早的分马力电机的制造企业之一，Parvalux为客户提供世界上最广泛和可靠的定制直流和交流电机而获得了良好的声誉。Parvalux在销售和生产电机和齿轮箱上不断加速全球化。
产品
直流无刷电机系列
直流有刷电机系列
交流电机系列
变速箱系列
型号：
SD 13
SD 18
SD 48
SD 28 GWS – SD 29 GWS
SD 13 GWS – SD 18 GWS
SD 48 – GWS
SD 21
SD 41
SD 8
SD 38
SD 28
SD 29
SD41
PM41
PM10
PM11
PM110
PM2
PM4
PM1 Family
Power 45 - 200 Watts
Speed 1500 - 4000 RPM
Torque 0.3 - 0.5 Nm
Voltage 12DC - 220DC
PM10_1
PM10 Family
Power 23 - 120 Watts
Speed 1500 - 4000 RPM
Torque 0.14 - 0.18 Nm
Voltage 12DC - 220DC
PM11 Family
Power 33 - 160 Watts
Speed 1500 - 4000 RPM
Torque 0.2 - 0.3 Nm
Voltage 12DC - 220DC
PM110 Family
Voltage 12DC - 220DC
PM2 Family
Power 60 - 330 Watts
Speed 1500 - 4000 RPM
Torque 0.4 - 0.6 Nm
Voltage 12DC - 220DC
PM3 Family
Power 33 - 200 Watts
Speed 1500 - 4000 RPM
Torque 0.2 - 0.4 Nm
Voltage 12DC - 220DC
PM4 Family
Power 45 - 260 Watts
Speed 1500 - 4000 RPM
Torque 0.3 - 0.5 Nm
Voltage 12DC - 220DC
PM5
PM5 Family
Power 60 - 300 Watts
Speed 1500 - 4000 RPM
Torque 0.4 - 0.6 Nm
Voltage 12DC - 220DC
PM50-50 Family
Power 90 - 190 Watts
Speed 1500 - 4000 RPM
Torque 0.16 - 1 Nm
Voltage 12DC - 220DC
PM6 Family
Power 75 - 410 Watts
Speed 1500 - 4000 RPM
Torque 0.5 - 0.8 Nm
Voltage 12DC - 220DC
PM60 Family
Power 105 - 575 Watts
Speed 1500 - 4000 RPM
Torque 0.7 - 1.1 Nm
Voltage 12DC - 220DC
PM7 Family
Power 7.5 - 40 Watts
Speed 1500 - 4000 RPM
Torque 0.05 - 0.08 Nm
Voltage 12DC - 220DC
PM70 Family
Power 80-354
Speed 1500-4000
Torque 0.51 - 0.85
Voltage 12DC - 220DC
PM8 Family
Power 13 - 55 Watts
Speed 1500 - 4000 RPM
Torque 0.08 - 0.11 Nm
Voltage 12DC - 220DC
PM9 Family
Power 19 - 90 Watts
Speed 1500 - 4000 RPM
Torque 0.12 - 0.17 Nm
Voltage 12DC - 220DC
PM90 Family
Power 113 - 656 Watts
Speed 1500 - 5000 RPM
Torque 0.7 - 1.3 Nm
Voltage 12DC - 220DC
PM95 Family
Power 168 - 984 Watts
Speed 1500 - 5000 RPM
Torque 1.1 - 1.9 Nm
Voltage 12DC - 220DC
PM1-L Family
Power 45 - 200 Watts
Speed 25 - 780 RPM
Torque 1,2 - 10.4 Nm
Voltage 12DC - 220DC
PM1-LB Family
Power 45 - 200 Watts
Speed 25 - 780 RPM
Torque 1.2 - 10.4 Nm
Voltage 12DC - 220DC
PM1-LH Family
Power 45 - 200 Watts
Speed 25 - 780 RPM
Torque 1.2 - 10.4 Nm
Voltage 12DC - 220DC
PM1-LHB Family
Power 45 - 200 Watts
Speed 25 - 780 RPM
Torque 1.2 -10.4 Nm
Voltage 12DC - 220DC
PM1-LIS Family
Power 45 - 200 Watts
Speed 4 - 667 RPM
Torque 1 - 74 Nm
Voltage 12DC - 220DC
PM1-LWS Family
Power 45 - 200 Watts
Speed 0.4 - 80 RPM
Torque 9 - 100 Nm
Voltage 12DC - 220DC
PM1-M Family
Power 45-200 Watts
Speed 21 - 970 RPM
Torque 1 - 7.9 Nm
Voltage 12DC - 220DC
PM1-MB Family
Power 45 - 200 Watts
Speed 21 - 970 RPM
Torque 1 - 7.9 Nm
Voltage 12DC - 220DC
PM1-MIS Family
Power 45 - 200 Watts
Speed 15 - 623 RPM
Torque 2 - 37 Nm
Voltage 12DC - 220DC
PM1-MM Family
Power 45 - 200 Watts
Speed 0.3 - 59 RPM
Torque 5 - 11.8 Nm
Voltage 12DC - 220DC
PM10-GB28 Family
Power 23 - 120 Watts
Voltage 12DC - 220DC
PM10-LIS Family
Power 23 - 120 Watts
Speed 4 - 667 RPM
Torque 1 - 55 Nm
Voltage 12DC - 220DC
PM10-LWS Family
Power 23 - 120 Watts
Speed 0.4 - 80 RPM
Torque 4 - 100 Nm
Voltage 12DC - 220DC
PM10-M Family
Power 23 - 120 Watts
Speed 21 - 970 RPM
Torque 0.5 - 5.3 Nm
Voltage 12DC - 220DC
PM10-MB Family
Power 23 - 120 Watts
Speed 21 - 970 RPM
Torque 0.5 - 5.3 Nm
Voltage 12DC - 220DC
PM10-MM Family
Power 23 - 120 Watts
Speed 0.3 - 59 RPM
Torque 5 - 11.8 Nm
Voltage 12DC - 220DC
PM10-MWS Family
Power 23 - 120 Watts
Speed 1 - 149 RPM
Torque 3.1 - 45 Nm
Voltage 12DC - 220DC
PM10-S Family
Power 23 - 120 Watts
Speed 21 - 970 RPM
Torque 0.5 - 4 Nm
Voltage 12DC - 220DC
PM10-SIS Family
Power 23 - 120 Watts
Voltage 12DC - 220DC
PM10-SS Family
Power 23 - 120 Watts
Speed 0.5 - 150 RPM
Torque 3 - 5.9 Nm
Voltage 12DC - 220DC
PM10-SWS Family
Power 23 - 120 Watts
Speed 1 - 101 RPM
Torque 4 - 11 Nm
Voltage 12DC - 220DC
PM11-GB28 Family
Power 33 - 160 Watts
Voltage 12DC - 220DC
PM11-LIS Family
Power 33 - 160 Watts
Speed 4 - 667 RPM
Torque 1 - 74 Nm
Voltage 12DC - 220DC
PM11-LWS Family
Power 33 - 160 Watts
Voltage 12DC - 220DC
PM11-M Family
Power 33 - 160 Watts
Voltage 12DC - 220DC
PM11-MWS Family
Power 33 - 160 Watts
Voltage 12DC - 220DC
PM11-S Family
Power 33 - 160 Watts
Voltage 12DC - 220DC
PM11-SIS Family
Power 33 - 160 Watts
Voltage 12DC - 220DC
PM2-L Family
Power 60 - 330 Watts
Speed 25 - 780 RPM
Torque 1.6 - 13.9 Nm
Voltage 12DC - 220DC
PM2-LB Family
Power 60 - 330 Watts
Speed 25 - 780 RPM
Torque 1.6 - 13.9 Nm
Voltage 12DC - 220DC
PM2-LH Family
Power 60 - 330 Watta
Speed 25 - 780 RPM
Torque 1.6 - 13.9 Nm
Voltage 12DC - 220DC
PM2-LHB Family
Power 60 - 330 Watts
Speed 25 - 780 RPM
Torque 1.6 - 13.9 Nm
Voltage 12DC - 220DC
PM2-LIS Family
Power 60 - 330 Watts
Speed 4 - 667 RPM
Torque 2 - 82 Nm
Voltage 12DC - 220DC
PM2-LWS Family
Power 60 - 330 Watts
Voltage 12DC - 220DC
PM2-M Family
Power 60 - 330 Watts
Voltage 12DC - 220DC
PM2-MB Family
Power 60 - 330 Watts
Voltage 12DC - 220DC
PM1 Family
Power 45 - 200 Watts
Speed 1500 - 4000 RPM
Torque 0.3 - 0.5 Nm
Voltage 12DC - 220DC
PM10_1
PM10 Family
Power 23 - 120 Watts
Speed 1500 - 4000 RPM
Torque 0.14 - 0.18 Nm
Voltage 12DC - 220DC
PM11
PM11 Family
Power 33 - 160 Watts
Speed 1500 - 4000 RPM
Torque 0.2 - 0.3 Nm
Voltage 12DC - 220DC
PM110
PM110 Family
Voltage 12DC - 220DC
PM2_1
PM2 Family
Power 60 - 330 Watts
Speed 1500 - 4000 RPM
Torque 0.4 - 0.6 Nm
Voltage 12DC - 220DC
PM3_1
PM3 Family
Power 33 - 200 Watts
Speed 1500 - 4000 RPM
Torque 0.2 - 0.4 Nm
Voltage 12DC - 220DC
PM4_1
PM4 Family
Power 45 - 260 Watts
Speed 1500 - 4000 RPM
Torque 0.3 - 0.5 Nm
Voltage 12DC - 220DC
PM5
PM5 Family
Power 60 - 300 Watts
Speed 1500 - 4000 RPM
Torque 0.4 - 0.6 Nm
Voltage 12DC - 220DC
PM50-50_1
PM50-50 Family
Power 90 - 190 Watts
Speed 1500 - 4000 RPM
Torque 0.16 - 1 Nm
Voltage 12DC - 220DC
PM6_1
PM6 Family
Power 75 - 410 Watts
Speed 1500 - 4000 RPM
Torque 0.5 - 0.8 Nm
Voltage 12DC - 220DC
PM60_1
PM60 Family
Power 105 - 575 Watts
Speed 1500 - 4000 RPM
Torque 0.7 - 1.1 Nm
Voltage 12DC - 220DC
PM7_1
PM7 Family
Power 7.5 - 40 Watts
Speed 1500 - 4000 RPM
Torque 0.05 - 0.08 Nm
Voltage 12DC - 220DC
PM70
PM70 Family
Power 80-354
Speed 1500-4000
Torque 0.51 - 0.85
Voltage 12DC - 220DC
PM8_1
PM8 Family
Power 13 - 55 Watts
Speed 1500 - 4000 RPM
Torque 0.08 - 0.11 Nm
Voltage 12DC - 220DC
PM9_1
PM9 Family
Power 19 - 90 Watts
Speed 1500 - 4000 RPM
Torque 0.12 - 0.17 Nm
Voltage 12DC - 220DC
PM90
PM90 Family
Power 113 - 656 Watts
Speed 1500 - 5000 RPM
Torque 0.7 - 1.3 Nm
Voltage 12DC - 220DC
PM95
PM95 Family
Power 168 - 984 Watts
Speed 1500 - 5000 RPM
Torque 1.1 - 1.9 Nm
Voltage 12DC - 220DC
GB0 Family
GB12 Family
GB12 Family
GB28 Family
GB28 Family
GB4 Family
GB4 Family
GB41 Family
GB41 Family
GB9_1
GB9 Family
L3P
