CR 直动式压力控制阀 序列号 22

插装式 高工作压力 350 bar 大流量 50 l/min

工作原理

— CR型阀是一种插装式直动型压力控制阀，它可安装在符合 D-10B阀座孔的集成块或阀板上。

— 该阀通常用于控制液压回路的大压力，也可用于限制液 压油缸(马达)运动变化过程中产生的峰值压力。

— 该阀具有5种不同的压力调整范围，大压力 350 bar。

— 作用到该阀上的回路压力与弹簧力相平衡。当达到设定的 压力时，该阀打开，多余油液通过T口直接回油箱。 — 可通过调整螺钉设定压力。通常使用沉头内六角螺钉形式，同时装有锁紧螺母和大调节限位器



Duplomatic压力控制阀CR系列简介

技术参数 (在油温 50°C，油液粘度 36 cSt条件下测得)

大工作压力 bar 350

大流量 l/min 50

环境温度范围 °C -20 / +50

油液温度范围 °C -20 / +80

油液粘度范围 cSt 10 ÷ 400

油液允许的高污染等级 根据 ISO 4406：汉1999 等级 20/达18/15

推荐油液粘度 cSt 25

质量 kg 0,16

表面镀锌处理 Fe // Zn 8 // B EN 12329
